COMPLETE MACHINE QUALITY | 13500KG |
RATED BUCKET CAPACITY | 0.57M³ |
ENGINE POWER RATING | 154KW |
ROTATION SPEED | 12.1RPM |
TRAVEL SPEED | 38/10KM/HR |
CLIMBING CAPACITY | 70% |
TRANSPORT LENGTH | 7350MM |
TRANSPORT WIDTH | 2523MM |
TRANSPORT HEIGHT | 3500MM |
TURNING RADIUS | 2468MM |
TURNTABLE HEIGHT FROM THE GROUND | 1260MM |
TURNTABLE WIDTH | 2480MM |
TURNTABLE END LENGTH | 2250MM |
MINIMUM GROUND CLEARANCE | 350MM |
DISTANCE FROM THE CENTRE OF THE SLEWING CENTRE TO THE CENTRE OF THE DRIVE WHEEL | 1780 FRONT / 1100MM REAR |
WHEELBASE | 2880MM |
WHEELBASE | 2240MM |
MAXIMUM DIGGING RADIUS | 7700MM |
MAXIMUM DIGGING DEPTH | 4477MM |
MAXIMUM DIGGING HEIGHT | 8336MM |
MAXIMUM UNLOADING HEIGHT | 6030MM |
ENGINES | QSB5.9-C210-30 |
MAIN CONTROL VALVE | TX-22 |
TRAVEL MOTORS | A6VM107 |
SLEWING MOTORS | SD79 |
HYDRAULIC MAIN PUMPS | K5V80 |
CENTRE JOINT | IMPORTED FROM KOREA |
