| Engine | |
| Model | Cummins QSB-3.9 |
| Type | In-line |
Inhale | Turbocharged |
| Number of cylinders | 4 |
| Bore | 102 |
| Piston stroke | 120 |
| Rated power | 110kw |
| Slewing system | |
| Drive mode | Hydraulic drive |
| Reduction mechanism | Planetary Gear Reducer |
| Swing Operation Brake | Wet multi-disc brakes |
| Spinning speed | 9rpm |
| Drives and Brakes | |
| Steering control | Hydraulic steering wheel control |
| Drive mode | Hydraulic drive |
| Travel motor | Axial piston hydraulic motors |
| Walking speed (high/low) | 38/10km/h |
| Service brake | Multi-piece brake |
| Parking brake | Multi-piece brake |
Operating Weight (Operator, Lubricant, Coolant, Full Fuel Tank & Standard) | |
| Boom | 4350mm |
| Stick | 2100mm |
| Bucket | 0.48m³(0.52m³) |
| Working weight | 12.5ton |
| Maximum Digging Force (ISO) | |
| Bucket | 72kN |
| Stick | 49kN |
| Hydraulic motor | |
| Travel motor | Axial plunger type x 1 |
| Swing Operation Brake | Wet multi-disc brakes |
| Main pump | |
| type | Axial piston pumps |
| Maximum flow | 2×176L/min |
| Fuel tank capacity | |
| Fuel tank L | 210 |
| Hydraulic tank (oil dipstick level) L | 130 |
| Technical parameter | |
| Shipping length | 7666mm |
| Shipping width | 2530mm |
| Transport height | 3150mm |
| Radius of gyration | 2370mm |
| The height of the turntable from the ground | 1220mm |
| Turntable width | 2410mm |
| Turntable tail length | 2100 |
| Minimum ground clearance | 310mm |
| The distance from the center of the slewing center support drive wheel | 1403 front/1257mm rear |
| wheel base | 2650mm |
| Wheel base | 1815mm |
| Maximum digging radius | 7597mm |
| Maximum digging depth | 4400mm |
| Maximum digging height | 8330mm |
| Maximum unloading height | 5965mm |
