| Complete machine quality | 8100kg |
| Rated bucket capacity | 0.29m³ |
| Engine power rating | 56.5KW |
Rotation speed | 9rpm |
| Travel speed | 30/14km/hr |
| Climbing capacity | 70% |
| Transport length | 6625mm |
| Transport width | 2400mm |
| Transport height | 3150mm |
| Turning radius | 2370mm |
| Turntable height from the ground | 1035mm |
| Turntable width | 2205mm |
| Turntable end length | 1825mm |
| Minimum ground clearance | 305mm |
| Distance from the centre of the slewing centre to the centre of the drive wheel | 1370 front / 1030mm rear |
| Wheelbase | 2400mm |
| Wheelbase | 1815mm |
| Maximum digging radius | 6725mm |
| Maximum digging depth | 3948mm |
| Maximum digging height | 7070mm |
| Maximum unloading height | 5040mm |
| Engines | 4TNV98L |
| Main control valve | HVSE-18-07-PLL300-BE12S |
| Travel motors | A6VM80 |
| Slewing motors | JMF47 |
| Hydraulic main pumps | HP5V85/AV10RC4S3MM-L1/1-TZW91 |
| Centre joint | FSJ150-37D-00000 |
