Product Specifications |
|||
|
Chassis model |
Faw Jiefang |
Lifting operation mode |
Push rod operation |
|
Full car size |
5995*1950*2700mm |
Large frame size |
250/300mm*150mm |
|
Wheelbase |
2800mm |
Slewing bearing |
1050-1200mm customizable |
|
Maximum lifting height |
25/28m |
Outrigger telescopic length |
Double 2 m |
|
Engine model |
Xichai engine |
Outrigger transverse span |
5950mm |
|
Gearbox model |
Wanliyang 8th gear |
Outrigger longitudinal span |
3400mm |
|
Slewing mechanism |
Vertical type (with balancing valve) |
Protection device |
Two-way hydraulic lock |
|
Boom structure type |
5m*6sections/5m*7sections |
Hydraulic pump |
Single pump |
|
Outrigger |
5 full hydraulic legs |
Reducer model |
Planetary reducer |
|
Engine power |
111kw(152 horsepower) |
Tires |
7.00R16LT |
|
Total length of boom |
30m/35m |
Braking system |
Air brake (ABS) |
|
Radius of rotation |
1.7m |
Steering mechanism |
Power steering (assist) |
|
Swing speed |
0-3rpm |
Main lifting mechanism |
5 ton/8ton winch |
