Highly configurable high performance rear components
1. Modular design of the cabin components for easy daily maintenance
2. Fuel filter system with oil and water separator
3. Improved performance of the cooling components
4. HD rear view camera for all-round visibility control
Original imported energy efficient, stable and reliable
1. Imported Rexroth hydraulic pump flow upgrade
2. Imported Yanmar engine
3. Imported wet axle system to enhance stability
The cab is thoughtfully laid out and luxuriously equipped to suit your needs
1. New and improved large LCD instrument panel
2. High air volume recirculation air conditioning system
3. Integrated operating panel
Ergonomic design is spacious, comfortable, flexible and convenient
1. Shock-absorbing suspension seat
2. More open driving view
3. Equipped with safety hammer and fire extinguisher
Longer and more stable working mechanism for heavy loads
1. Double tyre travel, no fear of flat tyres
2. Improved and strengthened working mechanism, which can adapt to harsh working conditions.
3. New working light, high brightness and wide angle lighting
4. New optimised transmission system, coordinated and reliable
| Engines | |
| Model | Yanmar 4TN98L |
| Type | Naturally aspirated diesel engines |
Cylinders | In-line four bar |
| Power rating | 46.3kw |
| Bore | 98mm |
| Piston stroke | 110mm |
| Hydraulic systems | |
| Main pump type | Axial piston pumps |
| Max. flow rate of main pump | 2x70L/min |
| Travel motors | Axial plunger type x 1 |
| Slewing operation brake | Wet multi-disc brakes |
| Hydraulic oil tanks | 93L |
| Fuel tank | 152L |
| Slewing systems | |
| Drive type | Hydraulic drive |
| Reduction mechanism | Planetary Gear Reducer |
| Rotational speed | 9rpm |
| Slewing operation brake | Wet multi-disc brakes |
| Drives and brakes | |
| Steering control | Hydraulic steering wheel control |
Drive type | Hydraulic drive |
| Travel motors | Axial piston hydraulic motors |
| Travel/parking brake | Multi-piece brake |
| Travel speed | 10-30km/h |
| Working weight | 7.5ton |
| Length of moving arm | 3720mm |
| Hopper length | 1750mm |
| Bucket capacity | 0.29m2 |
| Maximum digging force (ISO) | |
| Bucket | 51KN |
| bucket bar | 43KN |
| Overall dimensions and working range | |
| Dynamic transport dimensions (L) | 6400mm |
| Dynamic transport dimensions (width) | 2272mm |
| Dynamic transport dimensions (height) | 2932mm |
| Turning radius | 1986mm |
| Turntable (height above ground) | 1050mm |
| Turntable (height above ground) | 2260mm |
| Turntable (length of tail end) | 1790mm |
| Minimum ground clearance | 325mm |
| Distance from centre of rotation to centre of drive wheel (front) | 1396mm |
| Distance from centre of rotation to centre of drive wheel (rear) | 1012mm |
| Wheelbase | 2400mm |
| Wheelbase | 1790mm |
| Maximum digging radius | 6736mm |
| Maximum digging depth | 3851mm |
| Maximum digging height | 7364mm |
| Maximum unloading height | 5272mm |
