Highly configurable high performance rear components
1. The engine compartment has been carefully laid out to make routine maintenance easier and more convenient
2. High precision fuel filters, oil and water separators
3. Air Filters
Original imported energy efficient, stable and reliable
1. Imported Rexroth hydraulic pump
2. Japan imported Yanmar engine fuel saving and durable
3. Imported wet brake axle
The cab is a thoughtful layout, luxuriously equipped and easy to use
1. One button to switch between various scenes LCD display
2. Powerful performance cooler
3. Easy to remove breakaway feet
4. Easy-to-operate throttle knob
5. On-board multimedia playback system
Ergonomic design is spacious, comfortable, flexible and convenient
1. Spacious and luxurious multifunctional cab
2. Convenient safety hammer and fire extinguisher
3. Lift-up function for easy opening of front windows
Complete machine quality | 5580kg |
Rated bucket capacity | 0.21m³ |
Engine power rating | 46.3KW |
Rotation speed | 8rpm |
Travel speed | 30/10km/hr |
Climbing capacity | 70% |
Transport length | 6100mm |
Transport width | 1925mm |
Transport height | 2850mm |
Turning radius | 2350mm |
Turntable height from the ground | 986mm |
Turntable width | 1850mm |
Turntable end length | 1650mm |
Minimum ground clearance | 290mm |
Distance from the centre of the slewing centre to the centre of the drive wheel | 1240 front / 860mm rear |
Wheelbase | 2100mm |
Wheelbase | 1600mm |
Maximum digging radius | 6150mm |
Maximum digging depth | 3500mm |
Maximum digging height | 6070mm |
Maximum unloading height | 4340mm |
Engines | 4TNV98L |
Main control valve | KX-16 |
Travel motors | A6VM80 |
Slewing motors | 6SM300319 |
Hydraulic main pumps | AP2D28 |
Centre joint | FSJ150-37D-00000 |
